Features
Mounted securely on the container's steel frame, the IBC name plate performs three essential roles:
Displays mandatory UN certification markings.
Provides a flat, reliable surface for handling and safety labels.
Showcases the manufacturer's branding and identification.
Material and Durability
The plate is manufactured from 0.5 mm pre-galvanized steel, offering an ideal balance of strength and lightweight performance.
Before forming, the steel is coated with 80 g/m² of zinc, creating a proven protective barrier that:
Prevents rust and corrosion
Extends service life in demanding environments
Maintains a clean, professional appearance over time
Precision Manufacturing Process
Each IBC name plate is produced through a streamlined and automated process, ensuring consistency and high quality:
Material Preparation – Pre-galvanized steel coil is selected
Die Cutting – Precisely cut into rectangular shape
Stamping – Enhances rigidity and allows logo embossing
Hole Punching – Ensures accurate and consistent mounting points
The result is a uniform, ready-to-install panel suitable for large-scale production lines.
Optimized Size and Installation
The standard size of 555 mm × 410 mm is carefully designed to fit the IBC structure.
It perfectly covers four sections of the front grid, creating a clean and organized display area.
Installation is simple and reliable:
Two-screw mounting system
Secure attachment to the steel cage
Withstands vibration from transport and handling
This ensures stability even under forklift movement and long-distance shipping conditions.
Upgraded Design Features
This version of the IBC name plate incorporates two key enhancements for improved usability and safety:
Embossed Label Positioning Guide
A subtle raised border is integrated into the plate surface to guide label placement.
This feature:
Ensures labels are applied straight and consistently
Improves readability of safety and handling information
Reduces application errors during operation
Flanged Rounded Edges for Safety
The plate features a rolled perimeter flange, replacing traditional sharp-cut edges.
This design:
Eliminates burrs and sharp edges
Reduces the risk of cuts during handling and assembly
Enhances overall workplace safety
| PRODUCT FEATURES | ||
| This logo plate is designed to fit IBCs with a rounded-tube frame. | ||
| This logo plate is placed on the front of the IBC. | ||
| This logo plate is installed with screws. | ||
| This logo plate has an embossed guide line for label placement. | ||
| The sides of the plate have a rounded edge so its cut-protected. | ||
| TECHNICAL PARAMETERS | ||
| THICKNESS | 0.5mm | Standard |
| ZINC CODING | Z80 (>80g/㎡) | |
| SPECIFICATION | 555mm * 410mm | |
FAQ
Q:Could we create a placement guideline for applying the information sticker to the logo plate? This will ensure a clean and consistent appearance across all units.
A:Yes, the logo plate has been redesigned and now includes an embossed placement guide.
Q:I often receive complaints that the sides of the ID plates are too sharp, especially from the workshop during installation. Is there anything that can be done?
A:Yes. We have redesigned this plate. The new design rolls the sides of the plate to form a rounded edge. It is now cut-protected.
